SUNWARD SWE35UF - Grävmaskin
Beställ marknadens hetaste grävmaskiner - Upplev Sunward hos oss..
- Vikt 3850 kg
- Komfort-hytt med fullutrustning
- A/C klimatanläggning
- Kubota motor - D1703-E4B-SWD-1
- Lång bom
- Extra 7st hydrauluttag
- Gummilarver
- Bandbredd 1700mm
- LED belysning och arbetsbelysning
- Hammarhydraulik
- Slänthydraulik
- Bomsväng
- Vänder innanför larverna
- En Joystick med rulle
Vi utrustar maskinen efter dina önskemål och svensk standard/tillverkning på alla tillbehör.
Lägg till skopor, redskap, snabbfäste, powertilt, tiltmellandel, rototilt, mm
Pris enbart maskin: 345.900kr
Tillbehör:
Tiltmellandel
Powertilt
Rototilt
Vi har tillbehören du behöver, få allt på samma offert.
| SWE35UF Technical Parameters | |||
| Type of cab | Cabin | ||
| Bucket capacity | m3 | 0.11 | |
| Bucket width, std. | mm | 520 |
|
| Machine weight | kg | 3850 | |
| Dimension | Overal lenght | mm | 4890 |
| Overal height | mm | 2545 | |
| Overal width | mm | 1700 | |
| Ground clearance | mm | 270 | |
| Engine | Brand | Kubota | |
| Model | D1703-E4B-SWD-1 | ||
| Displacement | L | 1.647 | |
| Output | kW/rpm | 18.5/2200 | |
| Working ranges | Max cutting height | mm | 4925 |
| Max loading height | mm | 3400 | |
| Max digging depth | mm | 3120 | |
| Max digging reach | mm | 5390 | |
| Boom swing angel (L/R) | 72/44 | ||
| Front swing radius | mm | 2263 | |
| Tail swing radius | mm | 850 | |
| Max digging force (arm) | kN | 22.53 | |
| Max digging force (bucket) | kN | 31.8 | |
| Track | Type | Rubber crawler | |
| Rubber shoe width | mm | 300 | |
| Undercarriage | Track lenght | mm | 2163 |
| Length to center of rollers | mm | 1670 | |
| Length to center of track | mm | 1400 | |
| Traveling speed (High/Low) | km/h | 4.2/2.3 | |
| Gradeability | deg | 30 | |
| Swing speed | rpm | 9 | |
| Ground pressure | kpa | 32.3 | |
| Dozer size | Width | mm | 1700 |
| Height | mm | 366 | |
| Liting capacity | mm | 337/376 | |
| Hydraulic pumps | Type | 1 variable plunger pumps | |
| Flow rate | L/min | 1*88 | |
| Hydraulic pressure | Mpa | 24.5 | |
| Fuel tank capacity | L | 40 | |
| Hydraulic oil tank capacity | L | 41 | |
